Semi Conductive Tape

Introduction of Semi Conductive Tape:

Semi conductive self-adhesive tape is mainly used for making shielding layer of rubber-plastic insulated cable terminals and joints with rated voltage not exceeding 10kV, and can also be used for shielding structures required by other facilities.

Semi conductive tape is a kind of high-conformity,semi-conductive ethylene-propylene rubber insulating tape. It does not need vulcanization, has stable performance, and maintains stable electrical conductivity in a wide range of operating temperatures. Its electrical conductivity is affected by low-viscosity oil. Does not affect the conductivity of the semiconducting layer of the cable.

Product specifications of Semi conduction tape:

0.8MM*25MM*1M

0.8MM*25MM*2.5M

0.8MM*25MM*5M

0.8MM*50MM*2.5M

Or customized

Features of Rubber semi conductive tape:

Ethylene propylene rubber;

Semi-conductive (low resistivity);

maintain conductivity when stretched;

Easy to stretch, good conformability to irregular surfaces;

Stable performance under overload temperature (130℃/266oF);

Applicable to all solid dielectric cables;

Resistant to solvent, UV and moisture;

Suitable for high pressure joints and terminal materials;

for indoor and outdoor use;

Meets the requirements of ASTM D-4388, Class IV.

The surface is not sticky, and the layers are self-melting and not loose after winding

Good shape, suitable for wrapping various irregular surfaces

Easy to operate, no heating, no special tools required

Uniform electric field under high electric field, reducing electric field stress

Use step for Semi conductive tape:

1) Make sure the protected area is dry and free from sharp edges and corners

2) The wrapping process needs to be properly stretched by 10%-100% overlapped spiral and wrapping forward

3) The start and end positions need more than one turn to completely overlap the wrapping

4) After the first layer wrapping is completed, start wrapping the second layer back, and after the second layer is completed, repeat the first layer operation to wrap the third layer, and so on until the required layer thickness.

Semi conductive tape have many kinds according to different customer requirements, pls email to marketing@senpinghz.com for quotation.
